2 different functions with only 2 piping lines!
Features ①Generates magnetic force without electric wiring work. ②Equipped with release function. ③Excellent crushing power with one original cylinder.
| Class of excavator |
30~37ton |
|---|---|
| Other class |
6-8ton 【MC-76DM5】 12~14ton 【MC-135BDM5】 20~22ton 【MC-202BDM7】 30~37ton 【MC-352BDM7】 30~37ton 【MC-351DM9】 |
| Working pressure | 31.4MPa |
| Maximum working pressure | 34.3MPa |
| Weight |
[A]3870kg |
| Size |
A:2320mmB:1100mm Max opening C:180mm Cutter length |
| Tip crushing force | D:1080kN |
|
Central crushing force |
E:1770kN |
| Magnet diameter | F:φ900mm |
| Magnet working rate | 60%ED |
| Magnet electric consumption | 6.2kW |
| Maximum adsorption weight | Pig iron500kg, steel chips300kg, chips200kg |
